Allen-Bradley PowerFlex 6000 Firmware, Parameters, And Troubleshooting Manual

Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 189
Parameter Descriptions Chapter 2
P267 DC Bus Voltage Deviation Fault Filter
Time
150
P266 DC Bus Voltage Deviation Fault
Threshold
150
P277 DC Link Voltage Sag Scaling At Rated
Load
54
P396 Deceleration Control Enable 133
P435 Deceleration Control Frequency Range 134
P387 Deceleration Frequency 1 128
P389 Deceleration Frequency 2 129
P391 Deceleration Frequency 3 129
P434 Deceleration Iq Threshold 134
P385 Deceleration Process Enable 128
P405 Deceleration Ramp Transition Time 60
P399 Deceleration Time 59
P386 Deceleration Time 1 128
P388 Deceleration Time 2 128
P390 Deceleration Time 3 129
P392 Deceleration Time 4 129
P406 Deceleration Time Unit 61
P270 Delayed Lockout Time of Stop Operation 64
P278 Derating Control Enable Threshold 98
P279 Derating Control Output Filter Time 98
P182 Derating Function Enable 95
P302 Digital Output #0 Bit Selection 76
P303 Digital Output #0 Delay 76
P301 Digital Output #0 Logic 76
P300 Digital Output #0 Memory Address 75
P306 Digital Output #1 Bit Selection 77
P307 Digital Output #1 Delay 77
P305 Digital Output #1 Logic 77
P304 Digital Output #1 Memory Address 76
P310 Digital Output #2 Bit Selection 78
P311 Digital Output #2 Delay 78
P309 Digital Output #2 Logic 78
P308 Digital Output #2 Memory Address 77
P314 Digital Output #3 Bit Selection 79
P315 Digital Output #3 Delay 79
P313 Digital Output #3 Logic 79
P312 Digital Output #3 Memory Address 78
P318 Digital Output #4 Bit Selection 80
P319 Digital Output #4 Delay 80
P317 Digital Output #4 Logic 80
P316 Digital Output #4 Memory Address 79
No. Parameter Name Page
P322 Digital Output #5 Bit Selection 81
P323 Digital Output #5 Delay 81
P321 Digital Output #5 Logic 81
P320 Digital Output #5 Memory Address 80
P326 Digital Output #6 Bit Selection 82
P327 Digital Output #6 Delay 82
P325 Digital Output #6 Logic 82
P324 Digital Output #6 Memory Address 81
P330 Digital Output #7 Bit Selection 83
P331 Digital Output #7 Delay 83
P329 Digital Output #7 Logic 83
P328 Digital Output #7 Memory Address 82
P185 Drive Output Current Upper Limitation
Per Cooling Fan Input Voltage Drop
96
P186 Drive Start Delay 91
E
P019 Encoder Resolution 51
F
P101 Fan Control Fan Feedback Delay 89
P102 Fan Control Fan Stop Delay 90
P117 Fan Control Filter Cabinet Fan Fault Trip
Delay
90
P095 Fan Control Group #1 Fan Number 88
P096 Fan Control Group #2 Fan Number 88
P097 Fan Control Group #3 Fan Number 88
P098 Fan Control Group #4 Fan Number 89
P099 Fan Control Main Cooling Fan Cycle Time 89
P094 Fan Control Mode 88
P100 Fan Control Redundant Fan Working
Time
89
P106 Fan Control Transformer Cabinet Fan
Quantity Upper Limit
90
P116 Fan Control TX Cabinet Fan Fault Trip
Delay
90
P462 Fault Reset Timeout 125
P473 Fault-To-Bypass Delay When Starting
Motor
108
P472 Fault-To-Bypass Delay 107
P474 Fault-To-Bypass Minimum Frequency,
Zero through Rated Frequency
108
P471 Fault-To-Bypass 107
P298 Filter Time A For DC Bus Average Value 99
P299 Filter Time B For DC Bus Average Value 99
P211 Filter Time For Abnormal Output Voltage 142
