190 Rockwell Automation Publication 6000-TD004D-EN-P - November 2017
Chapter 2 Parameter Descriptions
P228 Filter Time For Ground Fault 145
P221 Filter Time For Output Over Voltage 144
P212 Filter Time For Output Short-Circuit 142
P232 Filter Time For Overspeed Fault (Lower
Limit)
146
P231 Filter Time For Overspeed Fault (Upper
Limit)
146
P272 Flux Control Compensation Gain 97
P273 Flux Control Regulation Control Enable 97
P268 Flux Control Signal Filter Time 97
P276 Flux Control-Lag Band Width 98
P271 Flux Delay 66
P454 Flux Time 70
P394 Flying Start Compensation Current
Threshold
114
P410 Flying Start Compensation Current
Threshold for Fast Compensation
115
P408 Flying Start Compensation Defer Restore
Voltage Speed Current Threshold
115
P393 Flying Start Compensation Enable 114
P395 Flying Start Compensation Frequency
Reduce Speed
115
P463 Flying Start Low/High Speed Regions
Boundary
116
P416 Flying Start Mode 115
P417 Flying Start Motor Speed Search
Timeout
116
P459 Flying Start Voltage Recovery Time
(High Speed Region)
116
P457 Flying Start Voltage Recovery Time (Low
Speed Region)
116
P187 Flying Start Voltage Threshold 114
P114 Flying Start-Current Comparison Delay
For Motor Speed Search
113
P115 Flying Start-Current Threshold For
Successful Motor Speed Search
114
P113 Flying Start-Initial Output Voltage 113
P383 Frequency At Fifth Point For 5 Point VF 69
P375 Frequency At First Point For 5 Point VF 67
P381 Frequency At Fourth Point For 5 Point VF 69
P377 Frequency At Second Point For 5 Point
VF
68
P379 Frequency At Third Point For 5 Point VF 68
P414 Frequency Command Deadband Upper
Limit
61
P413 Frequency Command Lower Limit 61
P415 Frequency Command Upper Limit 62
P251 Frequency Command-Low Frequency
Region Boundary
63
No. Parameter Name Page
P235 Frequency Deviation Warning
Cancellation Threshold
147
P237 Frequency Deviation Warning Delay 148
P236 Frequency Deviation Warning Threshold 147
G
P227 Ground Fault Detection Scaling
Correction Factor
145
P230 Ground Fault Trip Threshold 146
P256 Ground Fault Warning Cancellation
Threshold
149
P229 Ground Fault Warning Threshold 146
H
P110 Heating Current Threshold 136
I
P200 Ia Motor Current Memory Address 73
P202 Ic Motor Current Memory Address 74
P250 Input Contactor/Circuit Breaker Close
Delay
54
P073 Input Voltage Loss Filter Time 102
P295 Iq Filter Time For Slip Estimation 67
L
P195 Line CT Ratio 53
P196 Line CT Burden Resistor 53
P168 Line Current Filter Time 140
P177 Line Current Negative Sequence Fault
Delay
141
P176 Line Current Negative Sequence Fault
Threshold
141
P175 Line Current Negative Sequence Filter
Time
141
P171 Line Current Phase A Scaling Factor 73
P172 Line Current Phase B Scaling Factor 73
P173 Line Current Phase C Scaling Factor 73
P174 Line Current Positive Sequence Filter
Time
140
P161 Line Neutral Over Voltage Fault Delay 138
P160 Line Neutral Over Voltage Fault
Threshold
138
P159 Line Neutral Over Voltage Warning
Delay
138
P158 Line Neutral Over Voltage Warning
Threshold
137
P155 Line Over Voltage Fault Delay 137
P154 Line Over Voltage Fault Threshold 136
No. Parameter Name Page
