AMX MIO-R4 User Manual

List Box Buttons
93
T
PDesign4 Touch Panel Design Software (v2.10 or higher)
 When a new row is added, each button will have the same state properties (i.e. Fill Color,
Border Color etc.) as the button above it.
Adding Columns
1.
Select the List Box button in the Diagram Area.
2. Click the Add Column toolbar button. This function adds a column to the right-hand side of the list
box container.
 The width of the last column is used for the new column.
 If a column is selected, the new column will have the same width as the selected column.
 A column of buttons will appear on the right-hand side of the list and will contain the number
of buttons equal to the List Row (general) property.
 The maximum number of column allowed in a List Box Button is 20.
Deleting Rows and Columns from a List Box (Managed
Mode)
Deleting Columns
1.
Select the List Box button in the Diagram Area.
2. Click the Delete Column toolbar button to delete the right-most column in the list box container.
 After deletion the container will be resized.
 If only one column exists, this function is disabled.
Deleting Rows
1.
Select the List Box button in the Diagram Area.
2. Click the Delete Row toolbar button to delete the bottom-most row in the list box container.
 If the preferred row is deleted, the preferred row property should be set back to 1.
 If only one row exists, this function is disabled.
Cutting, Copying and Pasting a List Box (Managed Mode)
Cutting, copying and pasting a managed list box works only when the list box container is selected by
itself or when the list box container is selected along with other non-subordinate buttons.
 When one or more of the subordinate buttons are also selected, these features are no longer
available.
 TPD4 takes care of copying, pasting and deleting all the subordinate buttons for you. All you
have to do is select the container.
If a column is deleted, and is part of the Column Display Order field of the parent, the
Column Display Order field will be reset to "empty".
TPD4 does not support copying and/or pasting individual columns of a managed list
box.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
