Working With Pages
45
T
PDesign4 Touch Panel Design Software (v2.10 or higher)
Deleting Pages From a Project
To delete a page from the active project, select the page to delete in the Workspace Navigator (Pages
tab), and select Edit > Delete. The program will prompt you to verify the page deletion first.
Exporting Pages as Image Files
Use the options in the Export Page Images dialog to export one or more Pages in the active Project as
image files:
1. Select Panel > Export Page Images to open the Export Page Images dialog.
2. Use the checkboxes in the Pages & Popups list to select which Pages and Popup Pages to export.
3. Specify a target directory for the exported image files in the Export Directory field. Use the browse
button (...) to navigate to a target directory via the Browse For Folder dialog.
4. Specify a template for the resulting filenames in the Filename Template field. By default, the
template is set to include the Panel file name and the Page name into the generated image's file
name. As described on the dialog, use $P to insert the Panel name and $p to insert the Page name
into the exported file's name. The file extension is automatically, based on the File Format selection.
5. Use the Scale% up and down arrows indicate a percentage to down-scale the exported images. The
default setting is 100% (no scaling).
6. Select a image file type (JPG, PNG or BMP) for the resulting image files from the File Format
drop-down. If JPG is selected, you can select the desired level of image compression
7. Select Export current display state for buttons to capture the Pages as they are currently displayed
in the Design View, with the button's current display state. If this option is not selected, it will export
the buttons in the (default) Off state. By default, this option is enabled.
8. Select Export popup pages shown on pages to include any Popup Pages that are being displayed
on the Design View at the time of selection in the exported Page image file. If this option is not
selected, only the Page underneath any currently viewed Popup Pages will be exported. By default,
this option is enabled.
9. Select Export information overlay to include any function code information this is currently being
displayed on the Design View at the time of selection in the exported Page image file. If this option
is not selected, only the Page underneath any currently displayed function codes will be exported.
By default, this option is disabled.
All panels must include at least one page, therefore, deleting the last remaining page
is not allowed.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
