Working With Properties
120
TPDesign4 Touch Panel Design Software (v2.10 or higher)
General Properties (Cont.)
Touch Style This selection drop-down allows you to set a "touch style" for the selected but-
ton(s). Touch style describes the way buttons behave when pressed, in terms of
the shape and border style used.
For example, by using transparencies you could create a button that appears to be
round (although the actual shape of the button is rectangular), in which case you
may not the button to respond if the user presses outside of the circular border.
See the Working With Touch Styles and Active Touch section on page 76 for
details.
Type The Type (button type) defaults to the button type that was set when the button was
created. To change the button a different type, click Type to activate the button type
drop-down menu, containing a list of all available button types. You can use this
option to change the selected button's type.
Value Direction Set the orientation of the bargraph to Vertical or Horizontal. If the bargraph button is
Multi-State, the options are Vertical, Horizontal, or Touch Map.
Bargraph and Multi-State Bargraph buttons only.
Width/Height Size values. The Width and Height rows indicate the dimensions of the selected
button, in pixels. You can edit these fields to apply specific dimension info for the
button. Note that if you select the button and manually resize it on the page, these
constantly update to indicate the current dimensions.
