AMX MIO-R4 User Manual

Appendix B: G4 PanelBuilder
236
TPDesign4 Touch Panel Design Software (v2.10 or higher)
 Show any popups for the element.
 Show any popups for the linked Sub-Feature, when applicable.
 Show the Navigation element that linked to the element.
When navigating to a Device, Feature or Placeholder element from a Sub-Navigation element:
 Hide all popups on the page for that element.
 Perform the standard page flip to the page for that element.
 Show any popups for the element.
 Show any popups for the linked Sub-Feature, when applicable.
 Show the Navigation element that linked to the Sub-Navigation element or chain.
 For Sub-Navigations the user must set "Hide On Action" to No, then show the Sub-Navigation
element that linked to the element. Otherwise, the Sub-Navigation is not shown.
Info buttons are optional and only have to be included within an element if either the order the popup
pages is shown is important, if not all popup pages should be initially shown, or if an icon is used on the
corresponding Navigation or Sub-Navigation button. If the Info button is omitted, popup pages are
shown in alphabetical order.
Template Wide Conventions
 Text Replacement - The string "[text]" is required on the button wherever text is to be
replaced in the output file. The string "[text]" allows you to prepend/postpend text with
characters. If the text on a button to be replaced does not contain '[text]" then it is unchanged.
 Panel Title - A template can contain as many buttons named "[panelTitle]" as necessary, they
are replaced with the "Job Name" of the panel.
 Preview Images - A template must contain a main preview image and can also contain a
preview image for each element. The main preview image should be named '[preview].jpg"
(or .png). The element previews should follow the same naming conventions as their page
prefixes, i.e., "[device#DVD].jpg." There can only be one preview image per element.
Creating Navigation Elements
In order for a TP4 file to be successfully exported as a G4 PanelBuilder Template file (*.TPT), the TP4
project file must contain at least one Navigation Element.
A Navigation element consists of at least one popup (may contain multiple popups), and represents the
place where you make most navigation selections (i.e. a main menu page).
To create a basic Navigation element, create a new popup page (Panel > Add Popup Page), and name it
according to the naming convention required by G4 PanelBuilder for Navigation elements:
[nav#navName]pageName
 navName - The name of the Navigation as it will appear in G4 PanelBuilder.
 pageName - The base page name that will be used in the generated TP4 project.
Example implementation of Navigation popup, as seen in the "graphiclySound-Orange" template
(available from AMX). Note that the template includes several variations on the same Navigation theme,
offering different numbers of buttons. The example shown below (FIG. 95) is for the Navigation popup
named "[nav#3 Selections]Navigation 3", which as the name implies, contains three buttons.:
Any Sub-Navigation elements that may have been currently displayed will be hidden.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
