AMX MIO-R4 User Manual

File Transfer Operations
210
TPDesign4 Touch Panel Design Software (v2.10 or higher)
 Clear from status queue when complete: This option (enabled by default) clears each
transfer from the Transfer Status Window when complete.
5. Click Send or Receive to begin the transfer.
Panel File Transfers via Modem
In TPDesign4, file transfer operations are typically routed through the Master to which the target/source
touch panels are connected. To use a Modem as the transport type:
1. Select Transfer > Send to Panel or Receive From Panel. If you are not already connected to the
Master, the Connect dialog is invoked.
If you have already established a modem communication configuration, select it from the drop-
down list.
Otherwise, create and save a modem communication configuration via the Connection Settings
dialog:
a.
In the Name field, enter a name for this communication configuration. This is the name that will
appear in the drop-down list of the Connect dialog.
b. Select Modem from the Transport drop-down list.
c. Configure the selected modem connection (Baud Rate, Data Bits, Parity, Stop Bits, Flow
Control and Phone Number).
The suggested settings are:
d. Click OK to save the configuration and close the Connection Settings dialog
2. Click Connect in the Connect dialog to establish the modem connection.
3. Once communication is established, either the Send To Panel or Receive From Panel dialog is
invoked (depending on wether you selected Send to Panel or Receive From Panel from the Transfer
menu), displaying an online device tree, indicating all devices connected to the Master that are
currently online (according to the Filter setting). The online device tree lists the online devices by
System #, Device #, Description, (firmware) Version, and Manufacturer.
4. Use the Options checkboxes in the Send to Panel or Receive From Panel dialog to enable/disable
the following transfer options:
 Smart transfer (updated panel files only): Select to utilize the Smart Transfer feature, which
reduces the transfer time by only replacing those panel files that have been updated (relative to
the files already loaded in the panel). Any bitmaps, sound files and fonts that all already
•Baud Rate 38400
•Data Bits 8
•Parity none
• Stop Bits 1
•Flow Control none
• Phone Number Enter the telephone number of the target Master.
These settings must match those of the Modem.
To refresh the Online Devices Tree, disconnect and reconnect via the commands in
the Transfer menu.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
