TPDesign4 Project Files
24
TPDesign4 Touch Panel Design Software (v2.10 or higher)
Locked - the next time the panel file is selected to open; the Enter Access Password dialog
appears, prompting the user to enter the correct password to open the file. If the password is
not entered correctly, the file will not be opened at all.
To apply password protection to the open Project file:
1. Select File > Project Properties to open the Project Properties dialog - Project Information tab.
2. Click the down-arrow next to Protection to select a level of password protection from the drop-
down list (either read-only, locked or none).
3. Enter the password in the Password text field. Passwords can be from 1 to 259 characters in length.
4. Re-type the password in the Confirm field. If the passwords don't match, a "Passwords do not
match" message box is displayed, in which case you'll need to re-enter the password, or re-confirm
the password, or both.
5. Click Apply to save the changes and apply the specified password to the Project file.
Project Properties dialog - Panel Setup Information tab
Use the options in the Panel Setup Information tab (FIG. 22) to view/edit setup information associated
with the active project.
Use the options in the Panel Setup Information tab of the Project Properties dialog to view/edit setup
information associated with the active project/panel file. This dialog identifies the panel for which this
project was designed, and indicates it's screen resolution.
These protection options are not Windows file attributes, and are only relevant within
the context of the TPDesign4 application.
FIG. 22 Project Properties dialog - Panel Setup Information tab
