Working With Properties
131
T
PDesign4 Touch Panel Design Software (v2.10 or higher)
4. Click Grab Selected to grab (copy) the selected Properties.
5. With the Selection tool, select another Button, Page or Popup Page in the Design View.
6. Click Paint Selected to apply the properties that were "grabbed" from the first item to the selected
item(s).
Property Painter dialog
The Property Painter dialog provides a shortcut to applying properties to buttons by applying a pre-
defined set of General, Programming and States properties to a selected button, page, or popup page.
The Property Painter dialog can be accessed via the View menu. It is also invoked when a button, popup
page or page is selected with the Grab Properties tool. The Property Painter dialog can either be used in
conjunction with the Grab Properties and Paint Properties tools, or as a stand-alone dialog.
The items in this dialog include:
FIG. 62 Property Painter dialog -General Button Selected
The set of selected properties (but not their values) may be named and saved for
later use by entering a name in the Property Set text box.
Hold the Shift key and left-click to apply the properties to multiple selected Buttons.
• Property Set: Use this field to name the current set of Properties (resulting from using the
Grab Properties tool (or use of the Grab Selected button within the dialog) to
take a snapshot of the properties and values of the selected Button, Page or
Popup Page.
Once one or more sets of Properties have been named and saved, you can
use this drop-down list to select from the list of saved property configurations,
to apply to a selected Button, Page or Popup Page.
There are two default property sets to choose from (Appearance and Border,
Fill and Text Colors). These default property sets cannot be deleted.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
