AMX MIO-R4 User Manual

List Box Buttons
105
T
PDesign4 Touch Panel Design Software (v2.10 or higher)
Data List Commands - Rules
The following rules apply to the ^LDA, ^LDR and ^LDL Data List Commands:
 Leading and trailing spaces are ignored before and after opening and closing double quotes.
 Double quotes must be the first non-space character after the previous delimiter (,) and the last
non-space character before the following delimiter (or end of command).
 Within double quotes, the backslash (\) is used as an escape character. This is to allow double
quote literals within the string bounded by double quotes. When a backslash is parsed, the
next character is read as a literal value and the backslash is discarded.
 There are 2 cases in which you would use the backslash to escape a double quote literal within
the field, to escape another backslash (commas do not need to be escaped).
 Any data field that has a double quote literal as its first character MUST use double quotes to
delimit the field, then use the backslash to escape the double quote literal.
 List box commands contain comma-delimited fields, but you can use commas within the
fields. Use double-quotes to surround fields in which commas are needed.
Data List Commands (Cont.)
^LDT
Set column type
Sets the column type for a data list. Column is the index of the first type to set,
additional types sent are set in order.
Syntax:
"'^LDT-<list address>,<column>,<type>,<type>,...'"
Variables:
• list address = address where data resides
• column = the starting column number
• type = subsequent columns. 0 - Text; 3 - Channel; 4 - Page
Example:
SEND_COMMAND Keypad, "'^LDT-1,1,0,0,0'"
Sets the column type for the data list located at address 1. The column type
starts at column 1, the first column is Text, the second and third columns are
also Text.
^LDL
Modify data in a single
column
Modifies the data in a single column field. This can be used to load a data list
that has long text fields.
Syntax:
"'^LDL-<list address>,<column>,<uniflag>,<primary
data>,<new cell data>'"
Variables:
• list address = address where data resides
• column = the starting column number; numbering starts at 1
• uniflag = indicates unicode; 0 - No unicode, 1 - Uses unicode
• primary data = the "key" data column. The information in this column provides
each row with its uniqueness.
• new cell data = data information for a single field or "cell"
Example:
SEND_COMMAND Keypad, "'^LDL-1,1,0,Entry5,Music'"
The field located in column 1, in the row with the primary data "Entry5" and in
the data list located at the address of 1 is a text value of Music.

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
