Appendix C: TakeNote
Introduction
AMX Modero Touch Panels, TPI/4 Touch Panel Interfaces, and TPDesign4 software now come
Computer Control ready. In combination with the NXA-USBTN (FG070-603) USB stick, this
innovative application allows you to connect any computer to the NetLinx control network. For more
information, refer to the on-line literature at www.amx.com.
This 32MB USB Control Stick contains everything you need to implement both Computer Control and
TakeNote functionality including:
 The amxCC server application
 The configCC configuration utility
 NetLinx cc-GuestPC code module
 The TakeNote on-screen annotation application
USB Stick Specifications
FIG. 101 NXA-USBTN - TakeNote USB Computer Control Stick
NXA-USBTN Specifications
Dimensions (HWD): • 0.32" x 0.87" x 2.87" (8.0 mm x 22.0 mm x 73.0 mm)
Supported OS and
System Requirements:
• Windows XP and Windows 2000 operating systems
• 1 GHz (or higher) Pentium
®
processor
• USB port
• 256 MB of RAM
• Note: Other configurations may experience some performance impact while
remote clients are connected.
Included Applications • TakeNote
• Computer Control (G4CC)
Features:
Port compatibility • USB 1.1 and USB 2.0
LED • Blue LED indicates the drive connection status
Operating /Storage
Environments:
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 20% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
Included Accessories • Lanyard (neck strap)
• USB extension cable
• Quick Start Guide (93-070-603)

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
