General| Displacement | 500 cc |
|---|---|
| Transmission | 6-speed |
| Fuel Tank Capacity | 20 liters |
| Seat Height | 800 mm |
| Wet Weight | 235 kg |
| Bore x Stroke | 69 mm x 66.8 mm |
| Compression Ratio | 11.5:1 |
| Clutch | Wet multi-plate |
| Frame | Steel trellis |
| Wheelbase | 1505 mm |
| Ground Clearance | 190 mm |
| Max Power | 47.6 hp (35 kW) @ 8500 rpm |
| Max Torque | 46 Nm @ 6000 rpm |
| Front Suspension | 50 mm upside-down fork |
| Front Brake | Double floating discs, 320mm, 4-piston calipers |
| Rear Brake | Single 260 mm disc |
| Fuel System | Electronic Fuel Injection (EFI) |
| ABS | Dual-channel ABS |
| Front Tire | 120/70 R17 |
| Rear Tire | 160/60 R17 |
| Engine Type | Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder |
