1 - 12
SPECIAL TOOLS
ENGINE SPECIAL TOOLS
Tool Code Tool Name-Function Image
Standard tool commonly found
Measuring tool commonly found
This tool is used to measure the outer di-
mensions of parts.
Standard tool commonly found
Measuring tool commonly found
This tool is used to measure thicknesses.
0320097044000
Flywheel assembly tool
This tool serves to tighten the engine shaft
fl ywheel.
0320097043000
Tool to remove the magnetic cap from
the alternator cover
This tool serves to unscrew the magnetic
cap of the alternator cover.
03200097053000
Toothed wrench for clutch bell lock
This tool is used to disassemble the clutch
bell.
