Benelli TRK 502 Service Station Manual

ELE. - 57
Please refer to the features on the Texa diagnostic device for
managing the diagnostics. Hereunder are the main fault codes
and the necessary corrective actions.
DTC (Hex) Fault codes Solutions
5055
Replace ABS unit
5019
5017
5013
5018
5014
5053
Check battery voltage
5052
5035 Replace ABS unit
5043
Check connection of the speed sensors using a new sensor
5045
5042
Check phonic wheel for deformation or faults
5044
5025
Checkspeedsensors,distance,phonicwheel,andtyrespecications
5122
Replace ABS unit
5223
ACTUATORS
ABS ECU
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
