Brother HL-5590DN Service Manual

2-82
Confidential
 Error code C800
The memory size allotted for Secure Print was exceeded when saving Secure Print data.
 Error code D800
An error occurred while initializing the touch panel.
 Error code E000
An error occurred in the ROM check sum.
Error code E100
Program error
<User Check>
• Print the print data stored in the memory.
• Divide the print data and print them separately.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Panel firmware version and
main firmware version do not
match
Install the latest main firmware.
2
Connection failure of the panel
PCB flat cable
Reconnect the panel PCB flat cable.
3 LCD relay PCB failure Replace the LCD panel ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Malfunction of the main
firmware
Install the latest main firmware.
2 Main PCB failure Replace the main PCB ASSY.
