12. DISASSEMBLY PROCEDURE (TT UNIT)

12.1 Preparation

 Disconnecting Cables and Removing Accessories

Prior to proceeding with the disassembly procedure,

(1) Disconnect the following:

•AC cord

•Relay AC cord

(2) Remove the following:

• Paper trays

Fig. 3-143

AC cord

Paper trays

Relay AC cord
