Brother HL-5590DN Service Manual

2-20
Confidential
3.2 Error Messages
3.2.1 Non touch panel models
First line Scroll Description
Error
codes
Refer
to:
Cartridge Error Put the Toner
Cartridge back in.
The new toner sensor could not
detect the new toner cartridge
correctly.
4F01 2-50
Cooling Down Wait for a while The side thermistor of the fuser
unit or internal temperature sensor
detected a temperature higher
than the specified value.
6801 2-53
Cover is Open Close the Back Cover
of the machine.
The eject sensor detected that the
fuser cover was open.
6004 2-52
Close the Front Cover. The front cover sensor detected
that the front cover was open.
6001 2-51
Drum ! Slide the Green tab on
Drum Unit.
Detected discharge that may be
attributable to dirty corona wire on
the drum unit.
6A00 2-54
Drum End Soon
- The number of rotations of the
drum unit is reaching the upper
limit.
4000 2-49
Ignore Data
- Detected undecodable data during
printing. Received undecodable
PS data.
--- 4.11.1
Jam 2-sided Pull out the Duplex
Tray at the back of the
machine and remove
the jammed paper.
The registration front sensor does
not detect paper pass within the
specified time after the first side
was printed in duplex printing
mode.
7800 2-66
Jam Inside Open the Front Cover,
pull out the Drum Unit
completely and
remove the jammed
paper.
The eject sensor does not detect
paper pass after the registration
rear sensor detected the paper
pass.
7000 2-55
Jam MP Tray Remove the jammed
paper from MP Tray
and press Go.
When feeding from the MP tray,
the registration rear sensor does
not detect paper pass within the
specified time after the registration
front sensor detected paper pass.
7200 2-56
Jam Rear Open the Back Cover
and remove the
jammed paper.
The eject sensor remains ON
(paper pass detected) even after
the registration rear sensor
detected the end of paper pass.
7100 2-56
Jam Tray 1 Remove the jammed
paper from Tray 1.
When printing from the paper tray
1, the registration front sensor
does not detect paper pass within
the specified time after the T1
paper feed sensor detected paper
pass.
7302 2-57
