Brother HL-5590DN Service Manual

2-19
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
CA00 ― FA03 ―
D100 ― FB01 ―
D200 ― FB02 ―
D800
An error occurred while initializing the
touch panel.
2-82
FB03 ―
D900 ― FB04 ―
DA00 ― FB05 ―
DB00 ― FB06 ―
E000
An error occurred in the ROM check
sum.
2-82
FB07 ―
E100 Program error 2-82 FB08 ―
E400 ― FB09 ―
E500
An error occurred during access to the
DRAM in the main PCB ASSY.
2-83
FB0A ―
E600
Write error in the EEPROM of the
main PCB ASSY
2-83
FB0B ―
E701 System error in the flash ROM 2-83 FB0C ―
E702 Read error in the flash ROM 2-83 FB0D ―
E900
An error occurred while initializing the
NFC.
2-83
FB0E ―
EC00
A USB device not within the
specification is connected to the USB
terminal, resulting in over current.
2-83 FB0F ―
ED00 ― FC01 ―
EE00 ― FC02 ―
F900
The spec code was not entered
correctly.
2-83
FC03 ―
FA01 ― FC04 ―
FA02 ― FC05 ―
