4.10 Troubleshooting for PCB Problems

4.10.1 Main PCB failure

4.10.2 Memory full

- Turn the power switch OFF and then ON again.

- Install the latest main firmware.

- Check the print limit ID.

- Check that the print data is not damaged.

Step Cause Remedy

1 Main PCB failure Replace the main PCB ASSY.

- Print the accumulated data.

- Reduce the amount or resolution of the data.

Step Cause Remedy

1 Main PCB failure Replace the main PCB ASSY.
