5-44
Confidential
1.3.20 Display machine log information (function code: 80)
<Function>
This function is used to display the log information on the LCD.
<Operating Procedure>
Maintenance information
Non touch panel models
(1) Press the [â–²] or [â–¼] key in the initial
state of maintenance mode to display
"MAINTENANCE 80" on the LCD, and
press the [OK] key.
"MACERR_01:****" is displayed on
the LCD (**** indicates error code).
(2) Pressing the [Go] key displays the
next item. Press the [X] key, and the
machine returns to the initial state of
maintenance mode.
Touch panel models
(1) Press the [8], and then the [0] key in
the initial state of maintenance mode.
"MACERR_01:****" is displayed on
the LCD (**** indicates error code).
(2) Pressing the [â–²] or [â–¼] key changes
the display item.
(3) Press the [X] key, and the machine
returns to the initial state of
maintenance mode.
LCD Description
MACERR_##:0000
Machine error log (last ten errors)
*1
USB:000G8J000166
Serial number
*2
MAC:008077112233 MAC address
PCB:911309123456 Main PCB serial number
KTN_ERM:87%
Estimated remaining toner amount based on the average coverage
KTN_RRM:67% Estimated remaining toner amount based on the rotations of
develop roller
DRUM_PG:00000000 Printed pages for drum unit
PFMP_PG:00000000 Pages fed from PF kit MP
PFK1_PG:00000000 Pages fed from PF kit 1
PFK2_PG:00000000 Pages fed from PF kit 2
PFK3_PG:00000000 Pages fed from PF kit 3
PFK4_PG:00000000 Pages fed from PF kit 4
PFK5_PG:00000000 Pages fed from PF kit 5
FUSR_PG:00000000 Printed pages for fuser unit
LASR_PG:00000000 Printed pages for laser unit
TTL_PG:00000000 Total number of pages printed
DX_PG:00000000 Paper input for duplex tray
TTLPCPT:00000000 Total pages printed via PC
DX_PCPT:00000000 Total two-sided pages printed via PC
TTL_OTH:00000000 Total pages printed by other methods
DX_OTH:00000000 Total two-sided pages printed by other methods
