4-15

Confidential

7. IF YOU REPLACE THE MX / TT / LT

AND TT/LT CONTROL PCB

 What to do after replacement

• Installing Firmware (Main Firmware)

• Adjusting Left-end and Upper-end Print Position (Function Code: 45) (TT only)

 What you need to prepare

(1) One USB cable

(2) Create a temporary folder on the C drive of the computer (Windows

XP or later).

(3) Download utility (FILEDG32.EXE)

Copy this file into the temporary folder created on the C drive.

(4) Maintenance driver (MaintenanceDriver.zip)

When the maintenance driver is not installed on the computer, copy this file into the

temporary folder created on the C drive, and extract the copied file. Refer to “APPENDIX

3 INSTALLING THE MAINTENANCE PRINTER DRIVER” for the installation procedure.

(5) Firmware

Main firmware djf file

(ex. 1LINE: D001GJ_A.djf or D001GH_A.djf,

Touch panel: D001GG_A.djf)
