1.3.23 Quit maintenance mode (function code: 99)

This function is used to quit the maintenance mode, restart the machine, and return it to the

ready state. Also forcefully close the fuser unit error.

Non touch panel models

(1) Press the [▲] or [▼] key in the initial

state of maintenance mode to display

"MAINTENANCE 99" on the LCD, and

press the [OK] key. The machine quits

the maintenance mode and returns to

the ready state.

Touch panel models

(1) Press the [9] key twice in the initial

state of maintenance mode. The

machine quits the maintenance mode

and returns to the ready state.
