2-119

Confidential

4.11.4"Paper Low" message does not disappear

• Refill the paper in the appropriate paper tray.

• Turn the power switch OFF and then ON again.

Step Cause Remedy

Damaged plate-up plate in the

paper tray

Replace the paper tray.

2 Paper feed motor failure Replace the paper feed motor.

Damaged plate push-up

mechanism in the machine

Replace the main frame L ASSY.

4 Main PCB failure Replace the main PCB ASSY.
