10.7 LT pickup clutch

(1) Release the LT pickup clutch harness from the securing fixtures. Release the hook, and

remove the LT pickup clutch from the LT unit.

Fig. 3-108

LT unit

LT pickup clutch

LT pickup clutch harness

Hook
