5-9
Confidential
[2] Print worker switch (WSW) setting data (function code: 11)
<Function>
This function is used to print the worker switch settings and details.
<Operating Procedure>
Fig. 5-3
Non touch panel models
(1) Press the [â–²] or [â–¼] key in the initial
state of maintenance mode to display
"MAINTENANCE 11" on the LCD, and
press the [OK] key.
(2) "PRINTING" is displayed on the LCD,
and printing the CONFIGURATION
LIST (refer to the figure below) starts.
(3) When printing is completed, the
machine returns to the initial state of
maintenance mode.
Touch panel models
(1) Press the [1] key twice in the initial
state of maintenance mode.
"PRINTING" is displayed on the LCD,
and printing the CONFIGURATION
LIST (refer to the figure below) starts.
(2) When printing is completed, the
machine returns to the initial state of
maintenance mode.
