Brother HL-5590DN Service Manual

5-4
Confidential
1.2 List of Maintenance Mode Functions
* The maintenance mode functions shaded in the table can be used by end users.
Function
code
Function Refer to:
01 Initialize EEPROM parameters 1.3.1
09 Print quality test pattern 1.3.2
10 Set worker switches (WSW) 1.3.3
11 Print worker switch (WSW) setting data 1.3.3
12 Check LCD operation 1.3.4
13 Check control panel key operation 1.3.5
25 Display software version 1.3.6
28 Change setting for OnePushDemo function 1.3.7
32 Check sensor operation 1.3.8
33 Display LAN connection status 1.3.9
45
Change USB No. return value / Adjust left-end print
position / Adjust upper-end print position / Set HEXDUMP
mode
1.3.10
46
Adjust printable range for each speed level
(Full speed / Half speed for thick paper / Quiet Mode)
1.3.11
61 Adjust touch panel 1.3.12
67 Continuous print test 1.3.13
69 Print frame pattern (single-side printing) 1.3.14
70 Print frame pattern (duplex printing) 1.3.15
71 Print test pattern 1.3.16
74 Configure for country/region and model 1.3.17
77 Print maintenance information 1.3.18
78 Check main fan operation 1.3.19
80 Display machine log information 1.3.20
82 Display machine error code 1.3.21
88 Reset counters for consumable parts 1.3.22
91 Initialize EEPROM parameters 1.3.1
99 Quit maintenance mode 1.3.23
