Brother HL-5590DN Service Manual

1-9
Confidential
3. SERVICE INFORMATION
Model
HL-L5000D
HL-5580D
HL-5585D
HL-L5100DN
HL-L5100DNT
HL-5590DN
HL-L5102DW
HL-L5200DW
HL-L5200DWT
HL-L5202DW
Machine life 300,000 pages (A4/LTR) or 5 years
MTBF 4,000 hours
MTTR 0.5 hours
Maximum monthly
volume
Up to 50,000 pages
Periodical
maintenance
parts
*1
Fuser Unit Up to 200,000 pages
Laser Unit Up to 200,000 pages
PF kit 1
Up to 200,000 pages
*2
(Up to 100,000 pages
*2
)
PF kit 2 Up to 200,000 pages
PF kit 3 Up to 200,000 pages
PF kit 4 Up to 200,000 pages
PF kit 5 Up to 200,000 pages
PF kit MP Up to 50,000 pages
Specifications are subject to change without notice.
*1
As for replacement of the periodical maintenance parts, refer to “PERIODICAL
MAINTENANCE” in Chapter 7.
*2
PF kit 1 to 5 have same parts but PF kit 1 had a different life cycle from others to serve the
product strategy purpose. After reviewing the life cycle of periodical replacement parts, it's
changed to max. 200,000 pages for models with the below main firmware version or later,
and 100,000 pages for models with the older main firmware.
HL-L5000D (Except for Iran), HL-5580D, HL-5585D: Main Firmware D001GJ_D.djf (Ver.1.17)
HL-L5000D (For Iran): Main Firmware D004PT_C.djf (Ver.1.08)
HL-L5100DN, HL-L5100DNT, HL-5590DN, HL-L5102DW,
HL-L5200DW, HL-L5200DWT, HL-L5202DW: Main Firmware D001GH_F.djf (Ver.1.19)
However, what changed was only "Replace PF Kit1" error timing and the supplemental
parts have not been changed.
Model
HL-L6200DW
HL-L6200DWT
HL-L6202DW
HL-L6250DW
HL-L6250DN
HL-5595DN
HL-L6300DW
HL-L6300DWT
HL-L6400DW
HL-L6400DWT
HL-L6402DW
Machine life 300,000 pages (A4/LTR) or
5 years
600,000 pages (A4/LTR) or
5 years
MTBF 4,000 hours
MTTR 0.5 hours
Maximum monthly
volume
Up to 100,000 pages Up to 125,000
pages
Up to 150,000
pages
Periodical
maintenance
parts*
Fuser Unit Up to 200,000 pages
Laser Unit Up to 200,000 pages
PF kit 1 Up to 200,000 pages
PF kit 2 Up to 200,000 pages
PF kit 3 Up to 200,000 pages
PF kit 4 Up to 200,000 pages
PF kit 5 Up to 200,000 pages
PF kit MP Up to 50,000 pages
Specifications are subject to change without notice.
* As for replacement of the periodical maintenance parts, refer to “PERIODICAL
MAINTENANCE” in Chapter 7.
