3-20

Confidential

4 Bottom side of the top cover ASSY (Touch panel models)

Harness colors are subject to change for some reason.

Stack sensor PCB ASSY

NFC flat cable

NFC PCB ASSY

FG harness A (BK)

Flat core

Stack sensor harness

(WH, BK, RD)

LCD flat cable

KEY PCB flat cable
