3-134

Confidential

(2) Remove the seven taptite bind B M4x12 screws, and remove the drive frame MX.

Fig. 3-126

Drive frame MX

Taptite bind B M4x12

Taptite bind B M4x12

Taptite bind B M4x12

Taptite bind B M4x12

Drive frame MX
