2-7
Confidential
Part name Operation
MP separation roller,
MP separation pad
Separates the paper fed from the MP tray into single sheets.
MP paper empty actuator
(MP paper empty sensor)
Detects the paper in the MP tray.
Detects paper jams in the MP tray.
Eject stack actuator
(Eject stack sensor)
Detects the full of a machine output tray. (Touch panel models
only)
MX switching flapper Selects where the paper is ejected (output tray / MX).
MX jam lower actuator
(MX jam lower sensor)
Detects paper jams in the MX 1bin and 2bin.
Detects paper jams in the upper section of the output tray.
MX jam upper actuator
(MX jam upper sensor)
Detects paper jams in the MX 3bin and 4bin.
Detects paper jams in the rear side of the MX.
MX flapper Selects where the paper is ejected (MX 1bin / 2bin / 3bin / 4bin).
MX eject roller 1/2/3/4 Ejects the paper to each bin.
MX feed roller 1 Feeds the paper ejected from the machine to the MX feed roller
2, MX eject roller 1, or MX eject roller 2.
MX feed roller 2 Feeds the paper ejected from the MX feed roller 1 to the MX
eject roller 3 or MX eject roller 4.
MX bin stack actuator
(MX bin stack sensor)
Detects the full state of the MX 1bin / 2bin / 3bin / 4bin.
MX back cover sensor Detects open / closed MX back cover.
MX 2bin sensor,
MX 4bin sensor
Detects the MX 2bin and 4bin.
