Brother HL-5590DN Service Manual

2-16
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
8601 ― 8801 ―
8602 ― 8802 ―
8603 ― 8808
MX back cover sensor detected the
open cover when the MX was
selected as the output tray (before
registering printing data to engine).
2-74
8604 ― 8809
MX back cover sensor detected the
open cover when the MX was
selected as the output tray (after
registering printing data to engine).
2-74
8701
MX 1bin, 2bin, 3bin, or 4bin stack
sensor or machine stack sensor
detected the ejected paper full state at
the start of printing.
2-72
880A ―
8702
Machine stack sensor detected the
eject paper full state at the start of
printing when the machine output tray
was selected as the output tray.
2-73
8901 ―
8703 ― 8902 ―
8708
MX 1bin stack sensor detected the
eject paper full state at the start of
printing when the MX 1bin was
selected as the output tray.
2-73 8903
The back cover/duplex tray sensor
detected that the cover was open
when duplex printing is started.
(Before registering printing data to
engine)
2-75
8709
MX 2bin stack sensor detected the
eject paper full state at the start of
printing when the MX 2bin was
selected as the output tray.
2-73 8904
The back cover/duplex tray sensor
detected that the cover was open
during duplex printing. (After
registering printing data to engine)
2-75
870A
MX 3bin stack sensor detected the
eject paper full state at the start of
printing when the MX 3bin was
selected as the output tray.
2-73 8A01
The registration rear sensor detected
that the paper fed was smaller or
larger than the specified size in duplex
printing mode.
2-75
870B
MX 4bin stack sensor detected the
eject paper full state at the start of
printing when the MX 4bin was
selected as the output tray.
2-73
8A02 ―
870C
Machine stack sensor or MX 1bin
stack sensor detected the eject paper
full state at the start of printing when
the MX 1bin was selected as the
output tray and "Use Std. Tray when
full" setting was ON.
2-74 8B01
Detected that the TT was not turned
ON.
2-76
870D
Machine stack sensor or MX 2bin
stack sensor detected the eject paper
full state at the start of printing when
the MX 2bin was selected as the
output tray and "Use Std. Tray when
full" setting was ON.
2-74
8C00 ―
870E
Machine stack sensor or MX 3bin
stack sensor detected the eject paper
full state at the start of printing when
the MX 3bin was selected as the
output tray and "Use Std. Tray when
full" setting was ON.
2-74
8D01 ―
870F
Machine stack sensor or MX 4bin
stack sensor detected the eject paper
full state at the start of printing when
the MX 4bin was selected as the
output tray and "Use Std. Tray when
full" setting was ON.
2-74
8D02 ―
