Brother MFC-9330CDW Service Manual

2-26
Confidential
Jam Rear Open the Back
Cover and remove
the jammed paper,
then press [Start].
After the registration rear sensor
detected that paper has passed,
the eject sensor continues to detect
paper pass.
7100 2-58
Jam Tray Pull the paper tray
completely out of
the machine and
remove the
jammed paper
After the paper feed sensor detects
paper pass, the registration front
sensor does not detect paper
pass after a set period of time.
7300 2-59
Log Access
Error
Server Timeout,
contact your
administrator.
Timeout occurred with access
request sent to server due to
incorrect server address, network
disconnection, or inactive server.
C001 2-77
Authentication
Error, contact your
administrator.
User authentication is unavailable
due to incorrect user name,
incorrect password, or
asynchronous date and time
between the machine and server.
Otherwise, the directory name is
incorrect or you have no write
access.
C002
C003
2-77
Wrong Date&Time,
contact your
administrator.
The current time necessary for user
authentication is unavailable due to
machine clock not being set and
time not being obtained through
SNTP.
C004 2-77
Manual
Feed
Load paper
No paper is in the manual feed slot
when printing from the manual feed
slot.
8C00 2-62
No Belt Unit Open the Top
Cover, pull out all 4
Drum Units
completely and
install the Belt Unit.
The registration mark sensor
detected that no belt unit was set.
6400 2-53
No HUB
Support
-
USB device with a built-in hub was
connected.
--- 2-122
No Paper Reload paper in
Tray.
For printing by feeding paper from
the paper tray, the paper feed
sensor detected that no paper was
in the paper tray.
9302 2-65
No
Permission
Function Locked
The user does not have permission
to perform color printing when PC
print is performed.
--- 2-122
No Toner Open the Top
Cover, then install
Toner Cartridge.
As the electrical continuity of the
new toner detection terminal is
broken, the machine detected that
the toner cartridge was not
installed.
6101
6102
6103
6104
2-49
Error message
Description
Error
codes
Refer
to:
Upper line Lower line

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
