Canon imagePROGRAF IPF720 User Manual

Printer Driver
Paper Information on Printer Dialog Box (W indows)
On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and
congure printer driver settings for the paper source and media type.
Note
• T o display the Paper Information on Printer dialog box, on the Main sheet, click Get Information by
Media T ype . ( → P .347)
Setting Item Description
A Paper Source
Shows the Paper Source supported by the printer , as well as information
about the loaded paper . T o update the Paper Source and media type
settings in the printer driver , select the desired Paper Source option and
click OK .
350 Windows Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
