CAPINTEC, INC. CAPTUS
®
600
13:06
OK
ENRGY
MULTICHANNEL ANALYZER
SETUP
ENERGY SCALE : 200 keV
COUNTING TIME :> 60 SEC
COUNTING TIME BASE: REAL
PEAK
CUT OFF CHANNEL : 5
PEAK COUNTS : 100 X
P/T
Figure 18-7
Press F2 [PEAK] to scroll Peak Counts through the possible values (from 100 to 1024k)
When all entries are correct, press F4 [OK].
Up to 4 Regions of Interest may be entered. The Region of Interest number will be displayed
as shown in
Figure 18-8.
13:06
DEL
MULTICHANNEL ANALYZER
SETUP
FROM CHANNEL: >
ROI NUMBER: 1
OK
TO CHANNEL:
Figure 18-8
Entering Regions of Interest is optional.
If a pre-set Region of Interest is desired, input the “FROM” and “TO” channels (both must be
entered). The values range from 0 to 254.
Press F1 [DEL] to delete an ROI that has been entered.
Press F3 [OK] when the entries are correct.
If no ROI has been entered, or there was a ROI # 4, the last entry screen will be displayed:
November 07 MULTICHANNEL ANALYZER SETUP 18-5
