Capintec CAPTUS 600 - Page 52

CAPINTEC, INC. CAPTUS
®
600
1. CS137 STANDARD
0. Return to Setup Menu
14:32
2. CHI-SQUARE PROTOCOL
Figure 5-12
Press 1 to select CS137 STANDARD. The Cs137 Standard Probe/Well Selection Screen
(
Figure 5-13) will appear.
1. Well
2. Probe
0. Return to Previous Screen
14:32 CS137 Standard
Figure 5-13
Select which detector the standard is for by pressing 1 for WELL or 2 for PROBE. Even if you
have a single probe and use it as Probe and Well, you must still enter a Cs137 Standard for
both. The Cs137 Standard Screen (
Figure 5-14) will appear.
The word “PROBE” or “WELL” will appear on the screen to indicate which standard is being
entered. The same standard may be used for both Probe and Well but data must be input for
each in this section.
5-8 SYSTEM INITIALIZATION November 07
