CAPINTEC, INC. CRC
®
-25R
ENVIRONMENT REQUIREMENTS
Indoor use only. Pollution Degree 2, Altitude, and Installation Cat. II.
The instrument should be located where the level of the background radiation is as low and
as constant as possible.
The instrument should be located where the temperature is stable within a range of +50°F to
+85°F (+10°C to +30°C) and the maximum relative humidity is 90% non-condensing to
warrant maximum reliability and accuracy.
The instrument should be located where the barometric pressure is within a range of 27 – 31
inches of mercury (91 – 105 kilopascals).
CAUTION: If these environmental requirements are not followed, the instrument may
display erroneous readings.
POWER REQUIREMENTS
CAUTION: If the input voltage to the following items is not within the stated
limits, the unit may not function correctly or may be damaged.
Readout
100-240Vac, 50/60Hz, 245mA
Printers (optional)
Okidata Microline 320 (optional)
120Vac, 60Hz, 0.9A or
230/240Vac, 50/60Hz, 0.5A
Epson LX-300+II printer (optional)
99-132Vac, 50/60Hz, 0.6A (maximum 1.4A depending on the character type)
198-264Vac, 50/60Hz, 0.3A (maximum 1.4A depending on the character type)
Epson TM-295II Slip Printer (optional)
Input: 100-240Vac, 50/60Hz, 1.2A; Output: +24Vdc, 0.8A
Epson TM-U220D Roll Printer (optional)
Input: 100-240Vac, 50/60Hz, 1.0A max; Output: 24Vdc, 1.5A
HP DeskJet 6000/8000 Series Inkjet (or equivalent) printer (optional)
100-240Vac, 50/60Hz, 1.5A
Epson Stylus C86 Inkjet (or equivalent) printer (optional)
100-240Vac, 50/60Hz, 0.4A
March 15 SYSTEM SETUP 4 - 5
