CAPINTEC, INC. CRC
®
-25R
Figure 5-3 Date / Time Verification Screen will be shown. Press YES if it is correct. Figure 5-
2 Main Setup Menu will re-appear. Press NO to make corrections.
CHOOSING Ci or Bq
Measurement results can be displayed in Ci or Bq. The Ci/Bq key is used to switch the
measurement result between Ci and Bq. However, in some facilities, it may be decided to
disable this feature and allow measurements to be displayed only in Ci or only in Bq. When
the system arrives, it is set up to display in Ci and Bq.
To enable or disable Ci/Bq switching, press MENU from the Measurement Screen. Figure 5-
1 Main Menu will appear.
From Figure 5-1 Main Menu, select SETUP. Figure 5-2 Main Setup Menu will appear.
From Figure 5-2 Main Setup Menu, select CI/BQ. The current Ci/Bq selection will be shown.
The example below is for the default of Selectable (i.e., the user may select Ci or Bq)
Ci / Bq
SELECTABLE
OK? Y or N
Figure 5-6 Ci / Bq Verification Screen
If the displayed setting is correct, press YES. Figure 5-2 Main Setup Menu will re-appear.
If the displayed setting is not correct, press NO. Figure 5-7 Ci / Bq Selection Screen will
appear.
1. Set To Ci
2. Set To Bq
3. Ci or Bq
Figure 5-7 Ci / Bq Selection Screen
Press 1, 2 or 3 to select the desired setting.
March 15 SYSTEM INITIALIZATION 5 - 3
