CAPINTEC, INC. CRC
®
-25R
Selecting User Key
SELECT
USER KEY
U1 TO U5
Any Other Key To
Continue Setup
Figure 6-2 User Key Selection
Press any other key (except a USER key or the HOME key) to exit User Key Assignment and
return to Figure 6-1 Other Menu.
Current Assignment Display
Press the USER Key to which a nuclide is to be assigned. Figure 6-3 User Key Verification
screen will appear showing the current key assignment. In the example, Co60 has been
assigned to U1.
Note: From the factory, all USER Keys are set to NONE.
U1: Co60
OK? Y or N
Figure 6-3 User Key Verification
If no assignment has been made, the word “NONE” will appear after the key name.
If the assignment is correct, press YES and Figure 6-2 User Key Selection screen will re-
appear.
If the assignment is not correct, press NO. Figure 6-4 Nuclide Name Assignment Screen will
appear.
6 - 2 CHAMBER INITIALIZATION March 15
