CAPINTEC, INC. CRC

-25R

Source Verification

If the chosen source had data previously entered, the data will be displayed. The example

below is for Co57, which will be used in the Daily Test:

Co57

S/N: 1458

JAN 07 2006

100.0 mCi DAILY

OK? Y or N

Figure 6-7 Test Source Verification

If the data is correct, press YES. Figure 6-5 Test Source Menu will re-appear.

To change the data or to delete the source, press NO. Figure 6-8 Source Existence screen

will appear.

Do You Have

Co57 ?

Yes or No

Figure 6-8 Source Existence

If the selected Test Source is no longer being used, press NO and it will be deleted. Figure 6-

5 Test Source Menu will re-appear.

To input data for the selected Test Source, press YES. Figure 6-9 Entering Serial Number

screen will appear.

March 15 CHAMBER INITIALIZATION 6 - 5
