Cisco ASR 9000 Series Reference Guide

Task ID
OperationTask ID
readl2vpn
Examples
This sample output shows the EVPN EVI information with the VPN-ID and MAC address filter:
RP/0/RSP0/CPU0:router#show evpn evi vpn-id 185 mac 0024.be03.ce01
MAC address Nexthop Label vpn-id
-------------- --------------------------------------- -------- --------
0024.be03.ce01 3.100.100.100 16004 185
4.100.100.100 16004 185
ESI port key : 0x0000
Source : Remote
Flush Count : 0
This sample output shows the EVPN EVI information with the VPN-ID and inclusive-multicast filter:
RP/0/RSP0/CPU0:router#show evpn evi vpn-id 185 inclusive-multicast service-id 1850312 orig-ip
1.100.100.100
ISID Originating IP vpn-id
-------------- ------------------------------ ----------
1850312 1.100.100.100 185
1850312 2.100.100.100 185
1850312 3.100.100.100 185
1850312 4.100.100.100 185
This sample output shows the EVPN EVI inclusive-multicast information:
RP/0/RSP0/CPU0:router#show evpn evi inclusive-multicast detail
ISID: 1850312, Originating IP: 1.100.100.100 185
Nexthop: ::
Label : 16005
Source : Local
ISID: 1850312, Originating IP: 2.100.100.100 185
Nexthop: 2.100.100.100
Label : 16005
Source : Remote
ISID: 1850312, Originating IP: 3.100.100.100 185
Nexthop: 3.100.100.100
Label : 16005
Source : Remote
ISID: 1850312, Originating IP: 4.100.100.100 185
Nexthop: 4.100.100.100
Label : 16005
Source : Remote
This sample output shows the EVPN EVI information with the bridge-domain filter:
RP/0/RSP0/CPU0:router#show evpn evi bridge-domain tb1-core1 detail
EVI Bridge Domain Type
---------- ---------------------------- -------
145 tb1-core1 PBB
165 tb1-core2 PBB
185 tb1-core3 PBB
65535 ES:GLOBAL BD
This sample output shows the EVPN EVI detailed information:
RP/0/RSP0/CPU0:router#show evpn evi detail
EVI Bridge Domain Type
Cisco ASR 9000 Series Aggregation Services Router VPN and Ethernet Services Command Reference, Release
6.1.x
437
Provider Backbone Bridge Commands
show evpn evi
