overlay-encapsulation
To set a Network Virtualization Endpoint (NVE) interface to provide VXLAN, use the overlay-encapsulation
command in NVE interface configuration mode. To remove the configured encapsulation on the NVE interface,
use the no form of this command.
overlay-encapsulation {vxlan}
Syntax Description
Sets the NVE interface as a VXLAN Terminal EndPoint (VTEP).vxlan
Command Default
The NVE interface provides VXLAN encapsulation.
Command Modes
NVE interface configuration
Command History
ModificationRelease
This command was introduced.Release 5.2.0
Usage Guidelines
To use this command, you must be in a user group associated with a task group that includes appropriate task
IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator
for assistance.
Task ID
OperationTask ID
read, writeinterface
read, writetunnel
Examples
The following example shows an NVE interface configured for VXLAN encapsulation.
RP/0/RSP0/CPU0:router(config)# interface nve 1
RP/0/RSP0/CPU0:router(config-if)# overlay-encapsulation vxlan
Cisco ASR 9000 Series Aggregation Services Router VPN and Ethernet Services Command Reference, Release
6.1.x
677
VXLAN Commands
overlay-encapsulation
