The following example displays the number of packets matching the implicit deny in access list l2_acl:
RP/0/RSP0/CPU0:router# show access-lists ethernet-services l2_ACL hardware ingress implicit
location 0/0/CPU0
ethernet-services access-list l1_acl
2147483647 implicit deny any any (2300 hw matches)
The following example displays the number of packets matching a particular sequence number:
RP/0/RSP0/CPU0:router# show access-lists ethernet-services l2_ACL hardware ingress sequence
20 location 0/0/CPU0
ethernet-services access-list l2_acl
20 deny host 0002.0003.0004 host 0005.0004.0003 (5394 hw matches)
The following example displays statistics for the TCAM entry for Ethernet services access list l2acl_4:
RP/0/RSP0/CPU0:router# show access-lists ethernet-services l2acl_4 hardware ingress sequence
10 detail location 0/6/CPU0
Wed Jun 24 00:28:51.367 UTC
ACL name: l2acl_4
Format type : 1
Channel ID: 2
Sequence Number: 10
Grant: permit
Logging: OFF
Hits: 0
Statistics pointer: 0x150628
Number of TCAM entries: 1
idx = 0
Entry : 0 for ACE : 10
RAW value : 40 04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
RAW mask : 00 03 ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff ff
-------------------------------Field Details----------------------------------
outer_vlan_id value : 0000
outer_vlan_id mask : 0ffff
outer_vlan discard eligibility value: 00
outer_vlan discard eligibility mask : 01
outer_vlan_id cos value: 00
outer_vlan_id cos mask: 07
Ethernet type value : 0000
Ethernet type mask : ffff
Base app id value : 02
Base app id value : 00
Base acl id value : 0001
Base acl id mask : 0000
outer vlan id present value : 0
outer vlan id present mask : 1
inner vlan id present value : 0
inner vlan id present mask : 1
Mac source address value : 0000 0000 0000
Mac source address mask : ffff ffff ffff
Mac destination address value : 0000 0000 0000
Mac destination address mask : ffff ffff ffff
RP/0/RSP0/CPU0:router#
Related Commands
DescriptionCommand
Creates a copy of an existing Ethernet services access list.copy access-list ethernet-service, on page 648
Sets conditions for an Ethernet services access listdeny (ES ACL), on page 650
Controls access to an interface.ethernet-service access-group, on page 653
Cisco ASR 9000 Series Aggregation Services Router VPN and Ethernet Services Command Reference, Release
6.1.x
664
Layer 2 Access List Commands
show access-lists ethernet-services
