Key to Main Station/Remote Station: Front panel
the red FAULT indicator will flash. Possible causes of a fault include overvoltage,
overcurrent, short circuit to ground or severe brown-outs.
Loudspeaker. When a headset is connected [ B ] and selected [ E ], loudspeaker
output is diverted to the headphones.
Program feed audio level rotary control [Program].
l To increase the volume of the program feed to the loudspeaker /
headphones, turn clockwise (up to 360°).
l To decrease the volume, turn anticlockwise (up to 360°). As you increase or
decrease the volume, the level control LEDs pass through a range of
indicator colors:
LED color Volume level
Green Low
Amber / Green Low / Medium
Amber Medium
Red / Amber Medium / High
Red High
l To mute or unmute the program audio, push the rotary control.
Loudspeaker / Headphone audio level rotary control [Main]. To increase the
volume to the loudspeaker / headphones, turn clockwise (up to 360°). To decrease
the volume, turn anticlockwise (up to 360°). Push to mute or unmute.
As you increase or decrease the volume, the level control LEDs pass through a
range of indicator colors.
Main Station:
Remote Mic Kill [RMK]. Press to:
l Unlatch all latched talk keys for either all displayed Channels or all Channels
within the system (configurable within the Role)
Remote Station:
Option [OPT] – Can be configured as an RMK button, see Using the RMK [Remote
Page 18
