Key to Main Station/Remote Station front panel: Channel keyset
Feature Description
Display screen.
There are multiple screensaver options. If the Rotary controls are touched, this
screen also displays the sound level on the Channel (controlled by the rotary) and
the system information icons. See the next table for an explanation of system
information icons.
In Menu mode, the display screens display the four levels of menu. The menu
hierarchy proceeds left to right:
l The top level menu is presented in the first screen (furthest left on the front
panel).
l The lowest level menu is presented in the fourth screen (furthest right on the
front panel).
If the display is in Menu mode, the display screen times out of Menu mode and
displays the Channel label if no key is pressed for 20 seconds.
For more information about Menu mode, see Using the Menus
Rotary control. Turn to increase or decrease the listen volume level for the
Channel. Also, push the control to mute or unmute audio level. In Menu mode, use
the control to scroll menu items. To select menu items, press the control.
Talk key. Press to talk on the Channel and to all nodes (intercom devices and
systems) listening into the Channel.
Call key. Press to send a call signal to all nodes (intercom devices and systems)
listening into the Channel.
