HelixNet | User Guide

Key to Main Station: rear panel

Pin Function

Pin 1 Ground

Pin 2 Positive

Pin 3 Negative

Program Input (3-pin female XLR).

Pin Function

Pin 1 Ground

Pin 2 Positive

Pin 3 Negative

Line 1 (digital Partyline). (3-pin male and female XLR connectors).

Pin Function

Pin 1 Ground

Pin 2 +30V DC and Audio

Pin 3 -30V DC and Audio

Line 2 (digital Partyline). (3-pin male and female XLR connectors).

Pin Function

Pin 1 Ground

Pin 2 +30V DC and Audio

Pin 3 -30V DC and Audio

Page 26
