10-10 Preventive Maintenance
6. Press the key to move the ribbon carriage down and out of
the way.
7. Looking in from the side of the imager, locate the orange or
white platen roller and donor guide bar, shown in the following
figure.
8. If the Move Ribbon Carriage menu is displayed, press the key
to return to the Open Top Cover menu.
9. Clean any dust or other contaminants from the donor guide bar
using the platen roller cleaning wipe provided with the Platen
and Print Head Cleaning kit.
Platen
(orange or white)
Donor
guide bar
