Ax: indicates the status of the axis selected:
***456— ☞ means that axes 1-2-3 are to be calibrated, axes 4-5-6 are calibrated, axes 7-8
are not present
123456— ☞ means that axes 1,2,3,4,5,6 are calibrated, axes 7-8 are not present.
TTT456— ☞ means that the Turn_set operation is to be carried out for axes 1-2-3, axes
4-5-6 are calibrated, axes 7-8 are not present.
Pa: The First Field shows the number of active programmes, the Second Field indicates if there is
a PLC programme active: word PLC or no PLC programme active: word —
P ☞ indicates that the programming terminal is placed in the special housing on the
cabin.
- ☞ indicates that the programming terminal is not placed in the special housing on
the cabin.
The above information is shown on the first line of the status window, the second line shows the error and
system information messages.
·
SCROLLING WINDOW: this window displays the messages that the system sends to the operator and
the user programmes.
·
COMMAND WINDOW: this displays the system command menu described in the specific paragraph.
Some letters with special accents (for example: ã; õ; Ó; Á; Ú; Â) are not provided therefore
they appear without accent in the messages.
OPERATOR INTERFACE C3G Plus
3-20 00/1097
