Setting Power, Gain, and Attenuation in DAS mode
The RF parameters can be programmed in different manners if in DAS mode. The reason is to provide
flexibility with channel settings.
Setting RF Parameters for Individual Channel Filters
The user can click <Modify> in a Channel Filter row to update the Power and Gain settings for that channel
only.
For MU, the process is the same as for the BDA (See Figure 140):
• Navigate to <Device – Sites & Channels>.
• Click on <Modify> in a channel filter row to update the Power and Gain for that channel only
For individual RU, the UL Power and UL Gain can be changed by accessing the RU:
• Navigate to the RU at <Dashboard – Table View – Click on RU – Device – Sites & Channels> or
from <Home – RU Checkbox – Channels & Sites>
• Click on <Modify> in a channel filter row to update the Power and Gain for that channel only
Batch Setting RF Parameters to all Channel Filters for the System
The user can select <Batch Setting> and set the same Power and Gain for every channel or a specific range
of channels. In most cases this is the preferred method to reduce time.
For MU, the process is the same as for the BDA (See Figure 140):
• Navigate to <Device – Sites & Channels>.
• Click <Batch Setting> for a band to update the Power and Gain for all channels in the band.
If using <Batch Setting>, the user can set the Filter BW, DL_TAR, UL_TAR, DL_GAIN, UL_GAIN,
turn ON the Channel RF Switches for all channel filters in the band.
Start Channel No / End Channel No – the range of filters to be set in the Batch Setting
• Enter the RF parameters you would like to program and ensure the checkbox is checked for that
parameter then click <Save>.
For RU, the UL Power and Gain can be set for all RUs in the System:
• Navigate to <Device – Batch Setting>.
• Click the checkboxes for the RU devices you wish to configure the UL Power and UL Gain settings
on. If you want to configure all RUs, you can select <Select All Devices>.
• If using <Device - Batch Setting>, the user can set the UL_TAR, UL_GAIN, RU Output ATT, UL Mute
Switch, UL Mute Threshold, UL Gain Limit, and turn ON the System RF Switches for all channel
filters in the band for all RUs.
Start Channel No / End Channel No – the range of filters to be set in the Batch Setting
• Enter the RF parameters you would like to program and ensure the checkbox is checked for that
parameter then click <Save>.
See Figure 142 below for more details.
