Lighting Control Problems Lights will not come on.
Make sure you have a Time Schedule set up. A Time
Schedule is not Lighting Control. You can use the
same Time Schedule for several Lighting Controls.
Set up the Time Schedule first and then assign it to a
Lighting Control.
Set up a Time Schedule and go to Lighting Control.
1. Log into the Supervisory Controller.
2. Click the
Site Map icon.
3. Under
Control Status, click Lighting.
4. Click
Details.
5. Click
Inputs (found in the right-side of the
screen).
6. Click
Edit. Select and expand SCHEDULE IN.
7. Select and expand
TARGET and select the
desired schedule from the drop-down list.
8. Select and expand
PROPERTY and set to
OUTPUT. This will feed the schedule into
Lighting.
Make sure Lighting Control output is assigned.
Lights Will Not Come On With The
Photocell
Photocell is not recognized
by the controller.
Make sure the photocell is configured as an analog
input.
Verify that the type of light sensor is correct.
If using a light level sensor from another Supervisory
Controller, set it up on the controller it is associated
with in the Global Data section.
SYMPTOM POSSIBLE PROBLEM SOLUTION
