xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Figure 4-54 MLD Snooping Settings window
The fields that can be configured are described below:
Parameter Description
MLD Snooping State
Click the radio buttons to enable or disable the MLD snooping state.
Max Learning Entry Value
(1-1024)
Enter the maximum learning entry value.
Click the Apply button to accept the changes made for each individual section.
Click the Edit button to configure the MLD Snooping Parameters Settings for a specific entry.
Click the Modify Router Port
link to configure the MLD Snooping Router Port Settings for a specific entry.
After clicking the Edit button, the following page will appear:
Figure 4-55 MLD Snooping Parameters Settings window
The fields that can be configured or viewed are described below:
Parameter Description
VID
Specify the name of the VLAN ID.
VLAN Name
Specify the name of the VLAN for which IGMP snooping querier is to be configured.
Rate Limit
This displays the rate of IGMP control packets that the Switch can process on a
specific VLAN. The rate is specified in packet per second. The packets that exceed
the limited rate will be dropped.
Querier IP
Displays the querier IP address
Querier Expiry Time
Displays the querier expiry time.
Query Interval (1-65535)
Specify the amount of time in seconds between general query transmissions. The
default setting is 125 seconds.
109
